| No. | Name | Unit | Parameter |
| 1 | Maximum bending capacity | mm | ∅38*2mm |
| 2 | Maximum bending radius | mm | No limitation |
| 3 | Minimum bending radius | mm | 3 times bending radius |
| 4 | Maximum feed length | Mm | 6000 mm (according to customer requirements) |
| 5 | Maximum bending degree | ° | 360 |
| 6 | Feeding speed | mm/sec | 150mm |
| 7 | Bending servo motor power | Kw | 7 |
| 8 | Machine size | mm | 4700 X 1200 X 1400 |
| 9 | Machine weight | kgs | 2000 |
The system adopts full servo control, low energy consumption, no noise, high precision, high efficiency, high degree of freedom of bending, a mould multi-purpose, multi-language operating system, no need for professional training, this equipment is suitable for spiral bending, throwing arc bending, twisted bending, right-angle bending, etc., bending a variety of forms within the allowable space. Minimum bending R angle radius is 3.5 times the diameter of the pipe, the maximum is unlimited. The fastest speed is 150 mm per second, processing length can be customised. Suitable for copper pipe, stainless steel 304/316, aluminium pipe, A3 pipe, etc. Make bending easy.
To overcome the challenges of producing complex variable-radius (spline) continuous curves for aerospace and precision fluid piping for a leading high-end equipment manufacturer in Germany—where traditional fixed-radius bending fails and frequent mold changes incur high costs—Baorui Machinery deployed its advanced Free Bending solution; by leveraging full-servo spherical flexible die technology, the system enables one-shot forming of intricate 3D variable-radius curves. This technology not only eliminates expensive mold development costs but also significantly optimizes prototyping cycles with high-speed precision feeding at 150mm/s, ensuring superior ovality retention and exceptional fluid dynamic performance post-forming.
